MEAN WELL RSD 150 DC-DC Converter, 24V dc/ 6.3A Output, 16.8 → 31.2 V dc Input, 151.2W, Chassis Mount, +70°C Max
Tehnilised dokumendid
Spetsifikatsioonid:
Brand
Mean WellOutput Voltage
24V dc
Input Voltage Range
16.8 → 31.2 V dc
Power Rating
151.2W
Input Voltage Nominal
24 V dc
Output Current
6.3A
Mounting Type
Chassis Mount
Isolated
Yes
Number of Outputs
1
Isolation Voltage
4kV dc
Depth
36mm
Length
189mm
Railway Approved
Yes
Series
RSD 150
Load Regulation
±1%
Minimum Temperature
-40°C
Medical Approved
No
Maximum Temperature
+70°C
Distrelec Product Id
30156950
Päritoluriik
Taiwan, Province Of China
Toote üksikasjad
Mean Well 150W Railway Certified Regulated Isolated DC-DC Converter - RSD 150 Series
150W enclosed single output isolated DC to DC converters with a 2:1 wide input range and a 1U low profile of 36mm. The design of these single output isolated DC to DC converters complies with railway certificates (EN50155, IEC60571, IEC61373, EN50121-3-2) making them suitable for use in vehicles that are equipped with DC power source. These railway certified isolated DC to DC converters have a high efficiency circuit design and are semi-encapsulated for PCB protection.
Standards
Meet IEC60950-1(LVD)
Railway standards: Meet EN50155 / IEC60571 including IEC61373 for shock & vibration, EN50121-3-2 for EMC
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 236,00
€ 236,00 tk (ilma käibemaksuta)
€ 287,92
€ 287,92 tk (koos käibemaksuga)
1
€ 236,00
€ 236,00 tk (ilma käibemaksuta)
€ 287,92
€ 287,92 tk (koos käibemaksuga)
1
Lao andmed ajutiselt ei ole saadaval.
Palun kontrollige hiljem uuesti.
| kogus | Ühikuhind |
|---|---|
| 1 - 4 | € 236,00 |
| 5 - 9 | € 224,00 |
| 10 - 24 | € 212,00 |
| 25 - 49 | € 200,00 |
| 50+ | € 193,00 |
