Phoenix Contact STEP POWER Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 24V dc dc Output, 2.5A
Tehnilised dokumendid
Spetsifikatsioonid:
Brand
Phoenix ContactSeries
STEP POWER
Type
Switched Mode
Electrical Phase
1
Number of Outputs
1
AC or DC Input Voltage
ac
Input Voltage
85 → 264V ac
AC or DC Output Voltage
dc
Output Voltage
24V dc
Output Current
2.5A
Dimensions
72 x 61 x 90mm
Width
61mm
Height
90mm
Depth
90mm
Ripple And Noise
80mV Pk-Pk
Special Features
Low Profile Design
MTBF
1061650h
Maximum Temperature
+70°C
Mounting Type
DIN Rail Mount
Model
STEP-PS/ 1AC/24DC/2.5
Efficiency
>86%
Load Regulation
±1%
Standards Met
CE
Minimum Temperature
-25°C
Päritoluriik
Vietnam
Toote üksikasjad
Phoenix Contact STEP POWER Single Phase Power Supplies (PSU)
The single-phase STEP POWER generation of compact power supply units from Phoenix Contact have a high degree of efficiency and the low standby losses make for high power efficiency. The PSU’s are available with 24 V DC output voltage in various performance classes and overall widths as well as special voltages 5, 12, 15, and 48 V DC.
These PSU's (Power supply units) have been designed more specifically for building automation, however, are not limited to explicitly that use. Low idling and maximum efficiency help to achieve higher energy efficiency. Not to mention, these power supplies have a DIN rail notch took out of the housing to allow you effortless install, on a DIN rail. DIN Rail power supply's are great for cable management, having everything in a single cabinet for consistent maintenance and ease of use.
Approvals
UL/C-UL Recognised (UL 60950), UL/C-UL Listed (UL 508) approved
