Releco PCB Mount Power Relay, 24V dc Coil, 6A Switching Current, SPDT
Tehnilised dokumendid
Spetsifikatsioonid:
Brand
RelecoCoil Voltage
24V dc
Contact Configuration
SPDT
Mounting Type
PCB Mount
Switching Current
6A
Number of Poles
1
Latching
No
Terminal Type
Quick Connect
Length
28.8mm
Coil Resistance
742Ω
Coil Power
650mW
Height
35.4mm
Contact Material
Gold Plated
Minimum Operating Temperature
-40°C
Series
C10
Maximum Operating Temperature
+60°C
Isolation Coil To Contact
5kV
Depth
12.5mm
Maximum Switching Power AC
1.5 kVA
Application
Interface
Toote üksikasjad
10A SPCO Standard / 6A SPCO Bifurcated Contact - C10 Series
Relays have a test button, LED indication and mechanical flag indicator fitted as standard. The test button is colour coded and dual function, push to test or lift to latch. A removable marking label is fitted to each relay. The maximum switching voltage is 250Vac and the operating temperature is -20 to +60°C.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 24,80
€ 24,80 tk (ilma käibemaksuta)
€ 30,26
€ 30,26 tk (koos käibemaksuga)
1
€ 24,80
€ 24,80 tk (ilma käibemaksuta)
€ 30,26
€ 30,26 tk (koos käibemaksuga)
1
Lao andmed ajutiselt ei ole saadaval.
Palun kontrollige hiljem uuesti.
| kogus | Ühikuhind |
|---|---|
| 1 - 4 | € 24,80 |
| 5 - 9 | € 23,90 |
| 10 - 14 | € 23,40 |
| 15+ | € 22,90 |
