ABB System Pro M Compact S200M Miniature Circuit Breaker, 2-Pole, 20A, Type D, 440V ac AC, 125 V dc DC, 10 kA Breaking

RS Stock No.: 746-8172Brand: ABBManufacturers Part No.: 2CDS272001R0201 S202M-D20
brand-logo
View all in MCBs
RS Better World products put sustainability to work for your business—helping you cut energy and carbon, boost efficiency, and make choices you can trust.
Click here to find out more.

Technical Document

Specifications

Brand

ABB

Number of Poles

2

Product Type

Miniature Circuit Breaker

Current Rating

20A

Tripping Characteristics

Type D

Rated AC Voltage

440V ac

Rated DC Voltage

125V dc

Mount Type

DIN Rail

Breaking Capacity

10kA

Range

System Pro M Compact

Series

S200M

Terminal Type

Screw

IP Rating

IP20

Height

88mm

Depth

69mm

Standards/Approvals

IEC/EN 60898-1, IEC/EN 60947-2

Width

35mm

Better World Claim

Designed for Disassembly

Better World Product

Yes

Tripping Mechanism

Electromechanic, Thermal

Country of Origin

Germany

Product details

Type D Double Pole 10kA - System Pro M Compact

The System Pro M Compact range of Miniture Circuit Breakers from ABB, for use in Residential, Commercial and Industrial applications with a tripping characteristic of Type D

ABB System Pro M Single & Double Pole MCB's
