Cooper Bussmann, DR124, 0124 Shielded Wire-wound SMD Inductor with a Ferrite Core, 220 μH ±20% Wire-Wound 1.15A Idc
Technical Document
Specifications
Brand
Cooper BussmannInductance
220 μH
Maximum dc Current
1.15A
Package/Case
0124
Length
12.5mm
Depth
12.5mm
Height
4.5mm
Dimensions
12.5 x 12.5 x 4.5mm
Shielded
Yes
Tolerance
±20%
Maximum DC Resistance
669.6mΩ
Series
DR124
Core Material
Ferrite
Maximum Self Resonant Frequency
1MHz
Minimum Operating Temperature
-40°C
Inductor Construction
Wire-Wound
Maximum Operating Temperature
+125°C
Country of Origin
China
Product details
DR124 Series Magnetically Shielded Wire Wound Chokes
DR124 Series low profile SMD shielded drum core inductors with a ferrite core design. Applications for the DR series include: Notebook power; LCD panels; Computers, DVD players and portable power devices; DC-DC converters; Buck , boost, forward and resonant converters; Noise filtering and filter chokes.
125°C maximum operating temperature
Cooper Bussmann Non Standard SMT Inductors (Chokes)
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 4.18
€ 0.837 Each (In a Bag of 5) (Exc. Vat)
€ 5.18
€ 1.038 Each (In a Bag of 5) (inc. VAT)
Standard
5
€ 4.18
€ 0.837 Each (In a Bag of 5) (Exc. Vat)
€ 5.18
€ 1.038 Each (In a Bag of 5) (inc. VAT)
Stock information temporarily unavailable.
Standard
5
| Quantity | Unit price | Per Bag |
|---|---|---|
| 5 - 45 | € 0.837 | € 4.18 |
| 50 - 95 | € 0.757 | € 3.78 |
| 100 - 245 | € 0.618 | € 3.09 |
| 250 - 745 | € 0.597 | € 2.98 |
| 750+ | € 0.536 | € 2.68 |
