Jaeger Circular Connector, 3 Contacts, Cable Mount, Female
Technical Document
Specifications
Brand
JaegerNumber Of Contacts
3
Mounting Type
Cable Mount
Contact Gender
Female
Termination Method
Solder
Body Orientation
Straight
Minimum Operating Temperature
-50°C
Maximum Operating Temperature
+100°C
Country of Origin
France
Product details
’Rapid’ Cable Socket
Jaeger's 'Rapid' Series quick-disconnect socket insert has contact options ranging from 3 to 12 pin. This connector features a spring loaded coupling system for quick disconnection of the plug.
Jaeger Standard & Rapid Range
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 28.40
€ 28.40 Each (Exc. Vat)
€ 35.22
€ 35.22 Each (inc. VAT)
1
€ 28.40
€ 28.40 Each (Exc. Vat)
€ 35.22
€ 35.22 Each (inc. VAT)
Stock information temporarily unavailable.
1
Stock information temporarily unavailable.
| Quantity | Unit price |
|---|---|
| 1 - 9 | € 28.40 |
| 10 - 24 | € 25.60 |
| 25+ | € 22.70 |
