Yellow Plunger Tactile Switch, SPST 50 mA @ 24 V dc 0.9mm Through Hole

RS tootekood: 682-1193Bränd: OmronTootja Part nr.: B3F-3102
brand-logo
View all in Tactile Switches

Tehnilised dokumendid

Spetsifikatsioonid:

Brand

Omron

Contact Configuration

SPST

Terminal Type

Through Hole

Actuator Length

0.9mm

Actuator Colour

Yellow

Actuator Type

Plunger

Length

7.4mm

Width

7.3mm

Dimensions

7.4 x 7.3 x 3.15mm

Mounting Type

Through Hole

Contact Current Rating

50 mA @ 24 V dc

Operating Force

1.47 N

Height

3.15mm

Operating Temperature Range

-25 → +70°C

Mechanical Life

300000Operations

Contact Material

Gold Plated

Maximum Operating Temperature

+70°C

Minimum Operating Temperature

-25°C

Päritoluriik

Japan

Toote üksikasjad

Tactile Switches Omron B3F3000 series (6 x 6 mm)

Models with a vertical body and horizontal actuator.
