onsemi MC74HC573ADWR2G, Voltage Level Shifter 1, 20-Pin SOIC
Technical Document
Specifications
Brand
onsemiLogic Family
HC
Mounting Type
Surface Mount
Package Type
SOIC
Number of Elements per Chip
1
Output Type
3 State
Pin Count
20
Dimensions
12.95 x 7.6 x 2.4mm
Maximum Low Level Output Current
7.8mA
Maximum High Level Output Current
7.8mA
Propagation Delay Test Condition
50pF
Maximum Propagation Delay Time @ Maximum CL
225 ns @ 50 pF
Maximum Operating Supply Voltage
2 to 6 V
Maximum Operating Temperature
+125 °C
Minimum Operating Supply Voltage
2 V
Automotive Standard
AEC-Q100
Minimum Operating Temperature
-55 °C
