P-Channel MOSFET Transistor, 2.5 A, 60 V, 4-Pin SOT-223 STMicroelectronics STN3PF06
Tehnilised dokumendid
Spetsifikatsioonid:
Brand
STMicroelectronicsChannel Type
P
Maximum Continuous Drain Current
2.5 A
Maximum Drain Source Voltage
60 V
Package Type
SOT-223
Mounting Type
Surface Mount
Pin Count
4
Maximum Drain Source Resistance
200 mΩ
Channel Mode
Enhancement
Maximum Power Dissipation
2.5 W
Maximum Gate Source Voltage
-20 V, +20 V
Typical Gate Charge @ Vgs
16 nC @ 10 V
Number of Elements per Chip
1
Maximum Operating Temperature
+150 °C
Length
6.5mm
Width
3.5mm
Series
STripFET
Minimum Operating Temperature
-65 °C
Height
1.8mm
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
P.O.A.
tk (pakis 10) (ilma käibemaksuta)
Standard
10
P.O.A.
tk (pakis 10) (ilma käibemaksuta)
Standard
10
Lao andmed ajutiselt ei ole saadaval.
Palun kontrollige hiljem uuesti.
