TE Connectivity Expandable Braided Copper Silver Cable Sleeve, 10m Length 7.5 mm Cable Diameter, RayBraid Series

TE Connectivity Braided Cable Sleeve

The TE Connectivity RayBraid series cable sleeve is a braided and expandable protective cover with a sleeve diameter of 4mm and length of 10m. It is designed for the electrical screening of wire bundles, protecting them against any interference and physical damage. It is supplied on a tube former that facilitates assembly and is more robust than a braid supplied in a flattened form. The sleeve has a tinned copper screen for use in harsh environments and high temperatures.

Features and Benefits

• Easy removal from PVC former
• Highly usable expansion ratio (minimum 2:1)
• Maximum cable diameter is 7.5mm
• Minimum 93% and maximum 100% optical coverage
• Minimum cable diameter is 3.5mm
• Provides EMC screen for wires and cables

Certifications

• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
